Ceramic Electronic Components for EV Relays and HVDC Contactors, White Porcelain Case for Arc Extinguish
1. Description:
The new energy series ceramics are produced by high purity complex alumina and nano metallization. It is suitable for brazing of different materials such as copper, aluminum and felling. This series consist of HVDC relay ceramic housing, HVDC contactor ceramic shield, Fusegear ceramic case, ceramic connector for power battery cell.
2. Key Words:
Textured piezoelectric ceramics, morgan piezoelectric ceramics, lead zirconate titanate piezoelectric,manufacture samples , open mould ,aluminum oxide,thick-film nickel plating technology,copper and alloys,great limberness,Good corrosion resistance,High intensity,Good high-temperature resistance performance,High purity,uniform texture and good batch stability,95% alumina,hot injection pressing,white, pink or customized,high flexural strength, high tensile strength and good air tightness,EV vehicles, PHEV vehicles, power charing stations, power storage stations and urban commuting shuttles.
3. Parameters:
| Product Parameters |
| Physical Property | Material | 95% Alumina |
| Production Process | Hot Injection Pressing |
| Product Dimension | Per customers' drawing |
| Density (g/cm3) | 3.70-3.75g/cm3 |
| Water Absorption | 0% |
| Mechanical Performance | Flexural Strength (Mpa) | 310Mpa |
| Modulus of Elasticity (Gpa) | 310Gpa |
| Hardness (Gpa) | 12.9Gpa |
| Poisson Ratio | 0.23 |
| Thermal Character | Linear Thermal Expansion Coefficient | 7.2 |
| Heat Conductivity (W/mk) | 23 |
| Electrical Property | Dielectric Constant | 9.2 |
| Dielectric Loss Tangent (x10-4) | 8 |
| Insulation Strength (x106V/M) | 15 |
